Product Feature: 1. 8*325W solar panels 2. 12*150Ah/16*…
Product Feature:
1. 8*325W solar panels
2. 12*150Ah/16*150Ah gel batteries,DC24V/48V system
3. 4*50W/4*100W/6*100W LED light
4. Optional 6 to 9 meters manual/electric/ hydraulic mast
5. Dual axle solar light tower with Australia/ Europe/North America standard
| Tower Dimensions | |
| Length: | 4700mm |
| Width: | 2150mm |
| Height: | 2750mm |
| Weight: | 2410kg |
| Equipment Details | |
| Axle No.: | Dual Axle |
| Tire and Rim Size: | 15″ |
| Stabalizer | 4xManual |
| Supports: | |
| Drawbar: | A Frame |
| Tow Hitch: | 50mm Ball/ |
| 70mm Ring | |
| Working Temperature(℃): | -35-60 |
| Color: | Customized |
| Lighting Fixture Details | |
| Type of Lights: | LED |
| Lamp Wattage: | 50/100W |
| No. of lights: | 4/6 |
| Light Output(W): | 200/400/600 |
| Lumens per Watt: | 110 |
| Total Lumens(kW): | 22/44/66 |
| Mast Raise/ | Manual/Electric/ |
| Extension: | Hydraulic |
| Mast Height(m): | Optional |
| Mast Rotation: | 360 Degrees |
| Wind Rating Speed: | 100km/h |
| Working Lifetime(h): | 50000 |
| Coil Cable: | 1*cat5e+4*AWG13 |
